ABB AX400 Series pH/Redox Analyzers AX413
Overview
The AX413 conductivity transmitter is designed for use with ABB’s 2- and 4-electrode conductivity cells. The cost-saving transmitter measures low-range µS/cm and high-range mS/cm conductivity simultaneously, with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications.
- Two sensors, one instrument – reduces cost of investment
- Accurate measurements down to 0.055 µS/cm and up to 2,000 mS/cm
- Concentration measurement up to 15 % NaOH, 18 % HCl, 20 % H2SO4 or NaCl, or 40 % H3PO4
- True, high-purity temperature compensation for all pure water applications
- Problem-free measurements using auto-compensation of sensor fouling
- Dosing control functionality – long dose alarm and initial charge function
AX410:
designed for use with ABB's 2 electrode conductivity cells. The transmitter measures conductivity or resistivity with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications. Applications include demineralisation and reverse osmosis plants, semiconductor industry, power plants, biomedical and pharmaceutical industries and large steam-raising plants in Pulp & Paper, Steel and Chemicals.
AX411:
ABB AX400 Series pH/Redox Analyzers AX413
designed for use with two ABB 2 electrode conductivity cells. The cost-saving transmitter measures conductivity or resistivity with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications. Applications include demineralisation and reverse osmosis plants, semiconductor industry, power plants, biomedical and pharmaceutical industries and large steam-raising plants in Pulp & Paper, Steel and Chemicals.
ABB AX400 Series pH/Redox Analyzers AX413
AX413:
designed for use with ABB's 2 and 4-electrode conductivity cells. The cost-saving analyzer measures low-range µS/cm and high-range mS/cm conductivity simultaneously, with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications - click on the 'Data' tab to view.
AX416:
designed for use with ABB's pH and 2-electrode conductivity cells. The cost-saving transmitter simultaneously measures pH and conductivity or resistivity with exceptional accuracy and performance. It incorporates the latest technology to provide a highly reliable, yet flexible, feature-packed device that satisfies a diverse range of process monitoring and control applications - click on the 'Data' tab to view.
| AX410 | AX411 | AX413 | AX416 | |
| Input 1 | µS/cm | µS/cm | µS/cm | µS/cm |
| Input 2 | - | µS/cm | mS/cm | pH |
| Mounting | Panel, Wall, Pipe | Panel, Wall, Pipe | Panel, Wall, Pipe | Panel, Wall, Pipe |
| Power Supply | 4-wire AC & 24 V DC | 4-wire AC & 24 V DC | 4-wire AC & 24 V DC | 4-wire AC & 24 V DC |
| Current Outputs | 2 or 4 | 2 or 4 | 2 or 4 | 2 or 4 |
| Relay Outputs | 3 or 5 | 3 or 5 | 3 or 5 | 3 or 5 |
| PID Control | Yes | - | - | - |
| Hazardous Approval |
ATEX Type N (pending) FM / CSA Class 1 Div 2 (pending) |
ATEX Type N (pending) FM / CSA Class 1 Div 2 (pending) |
ATEX Type N (pending) FM / CSA Class 1 Div 2 (pending) |
ATEX Type N (pending) FM / CSA Class 1 Div 2 (pending) |
| Communications |
4 ... 20 mA PROFIBUS DP |
4 ... 20 mA PROFIBUS DP |
4 ... 20 mA PROFIBUS DP |
4 ... 20 mA PROFIBUS DP |
