Delivery informations
Availability available
Product description
Description 8 port Fast-Ethernet-Switch, managed, software Layer 2 Enhanced, for DIN rail store-and-forward-switching, fanless design
Port type and quantity 8 ports in total; 1. uplink: 100BASE-FX, MM-SC; 2. uplink: 100BASE-FX, MM-SC; 6 x standard 10/100 BASE TX, RJ45
Type RS20-0800M2M2SDAEHH09.0.
Order No. 943 434-003
More Interfaces
Power supply/signaling contact 1 x plug-in terminal block, 6-pin
V.24 interface 1 x RJ11 socket
USB interface 1 x USB to connect the AutoConfiguration Adapter ACA21-USB
Network size - length of cable
Multimode fiber (MM) 50/125 μm 0 - 5000 m, 8 dB link budget at 1300 nm, A = 1 d/km, 3 dB reserve, B = 800 MHz x km
Multimode fiber (MM) 62.5/125 μm 0 - 4000 m, 11 dB link budget at 1300 nm, A = 1 dB/km, 3 dB reserve, B = 500 MHz x km
Network size - cascadibility
Line - / star topology any
Ring structure (HIPER-Ring) quantity switches 50 (reconfiguration time < 0.3 sec.)
Power requirements
Operating voltage 12/24/48 V DC (9,6-60) V and 24 V AC (18-30) V (redundant)
Current consumption at 24 V DC 321 mA
Current consumption at 48 V DC 161 mA
Power output in Btu (IT) h 26.3
